Gas Cylinder Trolleys
<p>Gas cylinder trolleys are essential for the safe handling and transportation of gas cylinders. </p> <p>Choose from a selection of single and double gas cylinder trolleys.</p>
Cylinder Trolley with Lifting Plate
SKU: CT209Y
Gas cylinder trolley with lifting toe plate for easy unloading and retaining chain for security in transit. Large wheels at front of cylinder trolley allow use on rough terrain and 2 x swivel rear castors allow extra manouevrability.
- Overall size: 1375mm(h) x 610mm(w) x 700mm(l)
- 2 x front 350mm x 75mm cushion roller bearing wheels and 2 x rear 100mm nylon castors
- Max cylinder diameter: 240mm
- Toe plate size: 345mm(w) x 235mm(d)
- Toe plate lifting height: 200mm
- Weight: 30kg
- 3 year guarantee
SKU: TS171L
Welders trolley with tubular steel frame, cylinder retaining chain and welding rod holder. 2 x front 350mm x 75mm cushion roller bearing wheels and 2 x rear support castors for extra stability.
- Overall size: 1090mm(h) x 760mm(w) x 760mm(l)
- Capable of carrying two cylinders:
- 1 x oxygen cylinder 230mm(dia) x 1560mm(h)
- 1 x acetylene cylinder 236mm(dia) x 1200mm(h)
- Weight: 31kg
- 3 year guarantee
SKU: CPP21001955
Oxygen cylinder trolleys with tubular frame, sheet steel base and retaining straps to hold cylinders in place in transit. Ideal for use in healthcare environments.
- Choose from 3 sizes
- Max cylinder height: 140mm, 175mm, or 230mm
- Manufactured in accordance with BS2718, 1979.
- Fitted with anti-static metal centred 125mm wheels and front 100mm non-marking corner buffers
- 3 year guarantee
SKU: CPP21001956
Propane cylinder trolleys with tubular steel powder coated frame and retaining chain designed to safely manoeuvre 47kg propane cylinders. Ideal for use in warehouses, workshops and factories that deal with propane gas.
- Choose from 3 sizes
- Max diameter of cradle supports: 380mm
- Load capacity: 150kg (UDK)
- 3 year guarantee
Gas Cylinder Trolleys with Rear Support Wheels
SKU: CPP21001957
Gas cylinder trolleys with tubular steel frame and rear support wheels for easy manoeuvrability and stability when transporting gas cannisters. Ideal for use in factories, workshops and warehouses.
- Choose from models with painted or zinc plated frame
- Gas cylinder max diameter: 286mm
- Gas cylinder max volume: 40 Litre
- Weight: 20kg
- 3 year guarantee
Gas Cylinder Trolleys with Zinc Plated Frame
SKU: CPP21001958
Gas cylinder trolleys with tubular steel zinc plated frame for use in damp or outside areas. Retaining chain secures gas cannisters in transit.
- Choose from models with cushion or pneumatic wheels
- Gas cylinder max diameter: 140mm-250mm
- Gas cylinder max volume: 10, 20 or 40 Litre
- Weight: 16kg
- 3 year guarantee
